OpenStack Air-Gapped Image Factory (SA/Qi V2)

Purpose

This repository documents the design, implementation, and operation of an air-gapped OpenStack image build system based on Kolla and orchestrated by Zuul.

The system is intentionally split into two environments:

  1. Mirror Factory (Connected): prepares and versions all required artifacts using controlled internet access.
  2. Air-Gapped Build & Release (Disconnected): imports artifacts offline and builds OpenStack images with no internet egress.

This index is the authoritative navigation entry point for all versions.

Quick start navigation

Choose what you need:

Versions and roadmap

Current baseline

  • v2.0.0 — Two-environment model, manual artifact preparation, offline delivery, manual Zuul build trigger for OpenStack 2024.1.

Planned (examples — adjust as needed)

  • v2.1.0 — Bundle integrity hardening (signatures), completeness checks, stronger “no-egress” enforcement.
  • v2.2.0 — Promotion workflow (staging → production), approval gates, standardized release bundles.
  • v3.x — Expanded parity with upstream gating, automated update detection, deeper supply-chain controls.

The roadmap is tracked in: releases/ROADMAP.md

Release notes and evidence policy (per version)

Every version MUST have:

  • A release note describing scope, changes, and non-goals.
  • A repeatable “how to run” section referencing runbooks.
  • Evidence artifacts (digests/manifests/log pointers) sufficient to prove:
  • air-gap compliance (no internet dependency),
  • build success and output correctness,
  • traceability from artifact bundle to built images.

See:

Architecture and design

High-Level Design (HLD)

Low-Level Design (LLD)

Architecture Decision Records (ADRs)

ADRs capture why we made decisions, including rejected alternatives.

Implementation documentation

Implementation docs should be actionable, step-by-step, and environment-specific.

Operations and runbooks

Runbooks describe the recurring operational cycles and emergency procedures.

Troubleshooting

Troubleshooting docs must be symptom-based and include concrete checks.

Battle Log (what we went through)

This is the candid engineering record of the path to success:

  • misdocumentation,
  • undefined behavior,
  • bugs and sharp edges,
  • dead ends and reversals,
  • workarounds, patches, and hard-earned lessons.

Battle Log entries MUST be written so a new engineer can:

  • reproduce the issue context,
  • understand root cause,
  • apply a fix,
  • prevent regressions.

Battle Log index

Battle Log entry template

Create entries as battle-log/YYYY-MM-DD-short-title.md using:

  1. Context
    • What we were trying to do (component/version/environment).
  2. Expected behavior
    • What the docs/assumptions suggested would happen.
  3. Actual behavior
    • What happened (include relevant log snippets, error strings).
  4. Investigation
    • Hypotheses tested, commands run, configs reviewed.
  5. Root cause
    • The true underlying cause (include references to code/docs when possible).
  6. Fix / workaround
    • Exact changes applied (configs, patches, procedures).
  7. Preventative control
    • How we ensure this never happens again (tests, checks, guardrails).
  8. Outcome
    • What changed, what improved, remaining limitations.
  9. Links
    • Related ADRs, commits, issue tickets, log artifacts, runbooks.

Repository structure

This repository is organized as:

  • index.md (this file)
  • architecture.md (HLD)
  • lld/ (LLD modules)
  • implementation/ (deployment & configuration)
  • runbooks/ (operations)
  • troubleshooting/ (known issues & debug playbooks)
  • battle-log/ (the real story)
  • adr/ (decision records)
  • releases/ (release notes + roadmap)
  • results/ (evidence per version)
  • templates/ (sanitized config templates overview)

Change log (index)

  • v2.0.0: Project documentation baseline created (HLD/LLD/ops/troubleshooting/battle-log structure).
